2U 64 Channel Storage Server – Quant ComputeEdge CR2296

Technical Specification

  • Intel® Xeon® Silver 4310, 12-Core, 2.1 GHz
  • 32 GB DDR4 RECC, expandable up to 512 GB (8 DIMM slots)
  • 2 × 480 GB SATA SSDs
  • 8 × 3.5”/2.5” hot-swap drive bays
  • LSI 9364-8i RAID Controller (RAID 0/1/5/6/10/50/60)
  • NVIDIA® T1000 8 GB, 4 × DisplayPort (4K supported)
  • Multiple Expansion Slots:
  • 4 × PCIe 4.0 x16, 3 × PCIe 4.0 x8, 2 × M.2 x4
  • 2U Rackmount Server with Intel C620 Server-Class Chipset

Description

The Quant Compute Edge CR2296 is a powerful 2U rackmount server engineered for modern enterprise, surveillance, and AI-driven workloads. Featuring the Intel® Xeon® Silver 4310 processor, PCIe 4.0 architecture, and NVIDIA® T1000 GPU, it delivers exceptional performance, scalability, and reliability for data-intensive applications across edge and core environments.

Product Advantage and Applications

  • Built on Intel® Xeon® Scalable platform (Ice Lake architecture) with 12 cores at 2.1 GHz and 145W
  • TDP for balanced performance and efficiency.
  • Ideal for AI inference, video analytics, access control servers, virtualization, and IoT gateways.
  • Supports PCIe 4.0 for next-generation bandwidth in high-speed GPU, NIC, and RAID
    configurations.
  • Dual 800W (1+1) redundant power supply ensures 24/7 operational reliability
ENQUIRE NOW
File Name Size Download
Quant-Compute-Edge-CR2296.pdf 957.19 KB Download
