Q-SFP-SX-I<br><span>1G SFP MULTIMODE OPTICAL TRANSCEIVER, LC, UP TO 550 M</span>

Q-SFP-SX-I
1G SFP MULTIMODE OPTICAL TRANSCEIVER, LC, UP TO 550 M

Technical Specification

  • Form Factor: SFP hot-pluggable module
  • Data Rate: Up to 1.25 Gb/s
  • Wavelength: 850 nm VCSEL laser
  • Fiber Type / Connector: Multimode fiber with Duplex LC interface
  • Maximum Transmission Distance: Up to 550 m on MMF
  • Supply Voltage: Single +3.3 V power supply
  • Operating Temperature: −40°C to +85°C industrial range

Description

The Q-SFP-SX-I is a hot-pluggable 1G SFP multimode optical transceiver designed for Gigabit Ethernet short-distance communication. Operating at an 850 nm wavelength, it supports transmission distances up to 550 meters over multimode fiber and complies with SFP MSA standards, delivering reliable and efficient optical connectivity for industrial networking environments.

Product Advantage and Applications

  • Reliable Optical Performance
    Hot-pluggable SFP optical transceiver designed for stable Gigabit Ethernet connectivity
    Supports up to 1.25 Gb/s data rate for high-speed fiber communication
    Operates at 850 nm wavelength using VCSEL laser technology
    Transmission distance up to 550 m over multimode fiber
  • Industrial-Grade Reliability
    Wide operating temperature range −40°C to +85°C for industrial environments
    Stable performance in harsh networking conditions
    Durable design suitable for continuous operation
  • Flexible Integration and Compatibility
    Standard SFP form factor compatible with various switches, routers, and servers
    Duplex LC optical interface for reliable fiber connectivity
    Compliant with SFP MSA standards ensuring wide equipment compatibility
  • Intelligent Monitoring and Efficiency
    Digital Diagnostic Monitoring (DDM) for real-time monitoring of temperature, voltage, and optical power
    Low power consumption with single 3.3 V power supply
    Efficient optical performance for network infrastructure
  • Typical Network Applications
    Gigabit Ethernet networks (1000BASE-SX)
    Industrial Ethernet communication systems
    Switch-to-switch fiber connectivity
    Router and server fiber interfaces
    Fiber channel links for data communication
ENQUIRE NOW
File Name Size Download
Q-SFP-SX-I-2.pdf 1.08 MB Download
