TRINERGY RoomMax Series
Large Room Precision Cooling

Technical Specification

  • Indoor Model Range: LRP025 to LRP120
  • Total Cooling Capacity: 27.1–120.0 kW
  • Sensible Cooling Capacity: 24.9–108.0 kW
  • Air Volume: 8550–28000 m³/h
  • Compressor / Fan: DC variable frequency compressor, high-efficiency EC fans
  • Expansion / Refrigerant: High-efficiency electronic expansion valve, R410A
  • Heating / Humidification: 6–12 kW heating, 5–10 kg/h humidification
  • Power Supply: 380V / 3N – 50Hz
  • Indoor Dimensions: 900 × 995 × 1975 mm, 1100 × 995 × 1975 mm, 1800 × 995 × 1975 mm, or 2200 × 995 × 1975 mm
  • Indoor Net Weight: 320–880 kg; supports multiple CA-series outdoor unit options including dual outdoor sets

Description

The TRINERGY RoomMax Series is an advanced precision cooling platform for medium to large critical spaces. It is built to provide efficient, reliable temperature control for larger data centers, communication rooms, battery rooms, UPS rooms, and industrial equipment environments.

Product Advantage and Applications

  • High-efficiency large-room cooling with full frequency conversion design, DCVF compressor, EC fans, and optimized V/A-shaped evaporator heat exchange.
  • Easy control and maintenance through 7-inch HMI touchscreen, RS485, optional SNMP, hierarchical permissions, and support for up to 64 units.
  • Suitable for medium to large data centers, communication and telecom rooms, battery rooms, UPS rooms, industrial equipment rooms, and mission-critical infrastructure.
ENQUIRE NOW
File Name Size Download
TRINERGY-RoomMax-Series-Large-Room-Precision-Cooling-Data-Sheet.pdf 1.13 MB Download
