QUANT PROLINE RACK ONLINE UPS (6–20kVA Single-Phase) – PL-R006-X, PL-R010-X

Technical Specification

  • Power Range: 6kVA to 10kVA (6kW–10kW)

  • Wide Input Voltage: 110–288VAC

  • High Input Power Factor: ≥0.99

  • Unity Output Power Factor: 1

  • Wide Frequency Input: 40–70Hz

  • Multiple Output Voltages: 220/230/240VAC & 200/208VAC

  • Fast Load Response: ≤5%

  • Fast Recovery Time: ≤40ms

  • Low Harmonic Distortion: ≤1% (Linear), ≤5% (Non-linear)

  • Zero Transfer Time: Main to Battery & INV to BYP (0ms)

  • High Crest Factor: 3:1

  • External Battery Support

  • Adjustable Battery Quantity: 16–24 pcs

  • Cold Start Function

Description

The QUANT PROLINE Rack Online UPS is a high-performance, single-phase power protection solution designed for mission-critical rack installations. With true online double-conversion technology, 3-level inverter topology, and full digital DSP control, it ensures continuous, stable, and clean power for sensitive IT, ELV, medical, and industrial applications. This external-battery version allows flexible runtime configuration using 16–24 pcs battery banks, while maintaining high power density and superior performance.

Product Advantage and Applications

  • True Online Double Conversion
  • Zero transfer time ensures uninterrupted protection against all power disturbances.
  • High Power Density (up to 10 kW in 2U)
ENQUIRE NOW
File Name Size Download
QUANT-PROLINE-RACK-ONLINE-UPS-PL-R006-X-PL-R010-X.pdf 872.09 KB Download
